Applies to:
LVE 100 Wiring Diagrams
78562-H LVE 102, 103, 104, 380-415V, 3 Phase, 3+G FS, FSS, FSSS Wiring Diagram
78563-N LVE 102, 103, 104, 380-415V, 3 Phase, 3+G, FF, FFF, FFFF Wiring Diagram
78566-N LVE 102, 103, 104, 380-415V, 3 Phase, 3+G, SS, SSS, SSSS Wiring Diagram
78569-H LVE 103, 104, 380-415V, 3 Phase, 3+G, FFS, FFSS Wiring Diagram
80465-J LVE 104, 380-415V, 3 Phase, 3+G, FFFS Wiring Diagram
80467-J LVE 102, 103, 104, 380-415V, 3 Phase, 3+G, SF, SFF, SFFF Wiring Diagram
80469-J LVE 103, 104 380-415V, 3 Phase, 3+G, SSF, SSFF Wiring Diagram
80600-G LVE 103, 380-415V, 3 Phase, 3+G, SSD Wiring Diagram
80679-H LVE 104, 380-415V, 3 Phase, 3+G, SSSF Wiring Diagram
80824-G LVE 102, 103, 104, 380-415V, 3 Phase, 3+G, DS, DSS, DSSS Wiring Diagram
80950-G LVE 103, 104, 380-415V, 3 Phase, 3+G, DSF, DSFF Wiring Diagram
80958-E LVE 103 208-240V, 3 phase, 3+G, SSR Wiring Diagram
80961-F LVE 102, 103, 104, 380-415V, 3 Phase, 3+G, LS, LSS, LSSS Wiring Diagram
81516-G LVE 104 380-415V, 3 phase, 3+G, SSSR Wiring Diagram
81900-F LVE 102, 380-415V, 3 Phase, 3+G, SD Wiring Diagram
81991-G LVE 104, 380-415V, 3 Phase, 3+G, SSSD Wiring Diagram
82048-D LVE 102 380-415V, 3 Phase, 3+G, SR Wiring Diagram
82513-D LVE 103 380-415V, 3 Phase, 3+G, FSD Wiring Diagram
82549-D LVE 104 380-415V, 3 Phase, 3+G, FSSD Wiring Diagram
82552-D LVE 104 380-415V, 3 Phase, 3+G, DSSF Wiring Diagram
LOV Hood Exhaust Interlock Diagram
LEGEND
| Abbreviation | Definition |
|---|---|
| C | Control |
| CB | Circuit Breaker |
| CP | Control power |
| D | Drain |
| F | Fuse |
FL | Filter light |
| G | Ground |
J | Jumper |
| JE | JIB EMPTY |
| JLL | JIB low light |
| JM | JIB motor |
| JV | JIB valve |
| L1 | Line 1 |
| L2 | Line 2 |
| L3 | Line 3 |
LAV | Left add oil valve |
LDV | Left drain valve |
| LH | Left heat |
| LHL | Left high limit |
| LRV | Left return valve |
LS | Left safety |
| LTS | Left tilt switch |
| M | Motor |
N | Neutral |
| NFB | Neutral filter board |
| PB | Probe |
PS | Power switch |
| PW | Power |
| R | Relay |
| RAV | Right add oil valve |
RDS | Right drain switch |
| RDV | Right drain valve |
| RH | Right heat |
| RHL | Right high limit |
RRV | Right return valve |
RS | Right safety |
| RTIC | RTI Cable |
| RTIK | RTI Key |
| RTS | Right tilt switch |
SW | Switch |
| TR | Transformer |
| - | Ext. of same signal |
| MLTR1 | Line oil melter |
| MLTRN | Neutral oil melter |
